APC (AP6020A) RACK PDU, BASIC, 0U/1U, 100-240V/20A, 220-240V/16A, (13) C13
Power & UPS > PDUs
- Brand: APC
- Category: Racks & Cabinets
- SKU: AP6020A
- MPN: AP6020A
APC
APC AP6020A power distribution unit (PDU) 13 AC outlet(s) 0U/1U Black
- SKU
- CNZ-DD-010201
- MPN
- AP6020A
- Rating
- No reviews yet
−10%
Overview
Reliable rack power distribution designed to increase manageability and efficiency in the data center The output and input connections are (13) C13 Real-time remote monitoring of connected loads User-defined alarms warn IT and data center managers of potential circuit overloads to prevent accidental power loss to critical equipment.
Key features
- PDU types: Basic
- Type: Single-phase
- Rack capacity: 0U/1U
- Mounting: Horizontal/Vertical
- Product colour: Black
- AC outlets quantity: 13 AC outlet(s)
- Power plug: C20 coupler
- AC outlet types: C13 coupler
- Output connections: IEC 320 C13
- Nominal input voltage: 100-240 V
- AC input frequency: 50 - 60 Hz
- Maximum current: 20 A
- Load capacity: 3680 VA
- Maximum input current per phase: 16 A
- Maximum total current draw per phase: 16 A
- Maximum power: 3680 W
- Compliance certificates: RoHS
- Certification: cUL Listed, CE, EAC, IRAM, PSE, UL Listed, VDE, REACH
- Operating temperature (T-T): 0 - 50 °C
- Storage temperature (T-T): -15 - 60 °C
- Operating relative humidity (H-H): 5 - 95%
- Storage relative humidity (H-H): 5 - 95%
- Operating altitude: 0 - 3048 m
- Width: 44 mm
Specifications
Power
| Nominal input voltage | 100-240 V |
|---|---|
| AC input frequency | 50 - 60 Hz |
| Maximum current | 20 A |
| Load capacity | 3680 VA |
| Maximum input current per phase | 16 A |
| Maximum total current draw per phase | 16 A |
| Maximum power | 3680 W |
Design
| PDU types | Basic |
|---|---|
| Type | Single-phase |
| Rack capacity | 0U/1U |
| Mounting | Horizontal/Vertical |
| Product colour | Black |
Certificates
| Compliance certificates | RoHS |
|---|---|
| Certification | cUL Listed, CE, EAC, IRAM, PSE, UL Listed, VDE, REACH |
Logistics data
| Total carbon footprint (kg of CO2e) | 38.04 |
|---|
Packaging data
| Package weight | 2.02 kg |
|---|---|
| Package width | 210 mm |
| Package depth | 76 mm |
| Package height | 436 mm |
Ports & interfaces
| AC outlets quantity | 13 AC outlet(s) |
|---|---|
| Power plug | C20 coupler |
| AC outlet types | C13 coupler |
| Output connections | IEC 320 C13 |
Weight & dimensions
| Width | 44 mm |
|---|---|
| Depth | 93 mm |
| Height | 388 mm |
| Weight | 1.5 kg |
Operational conditions
| Operating temperature (T-T) | 0 - 50 °C |
|---|---|
| Storage temperature (T-T) | -15 - 60 °C |
| Operating relative humidity (H-H) | 5 - 95% |
| Storage relative humidity (H-H) | 5 - 95% |
| Operating altitude | 0 - 3048 m |
