APC Rack PDU. Basic. 0U/1U. 100-240V/20A. 22 Rack PDU. Basic. 0U/1U. 100-240V/20A. 220-240V/16A. (13) C13
Brand: APC Category: UPS Systems SKU: 3298830 MPN: AP6020A Home UPS Systems APC APC APC AP6020A power distribution unit (PDU) 13 AC outlet(s) 0U/1U Black Overview Specifications Questions Overview Reliable rack power distribution designed to increase manageability and efficiency in the data center The output and input connections are (13) C13 Real-time remote monitoring of connected loads User-defined alarms warn IT and data center managers of potential circuit overloads to prevent accidental power loss to critical equipment.
Key features PDU types: Basic Type: Single-phase Rack capacity: 0U/1U Mounting: Horizontal/Vertical Product colour: Black AC outlets quantity: 13 AC outlet(s) Power plug: C20 coupler AC outlet types: C13 coupler Output connections: IEC 320 C13 Nominal input voltage: 100-240 V AC input frequency: 50 - 60 Hz Maximum current: 20 A Load capacity: 3680 VA Maximum input current per phase: 16 A Maximum total current draw per phase: 16 A Maximum power: 3680 W Compliance certificates: RoHS Certification: cUL Listed, CE, EAC, IRAM, PSE, UL Listed, VDE, REACH Operating temperature (T-T): 0 - 50 °C Storage temperature (T-T): -15 - 60 °C Operating relative humidity (H-H): 5 - 95% Storage relative humidity (H-H): 5 - 95% Operating altitude: 0 - 3048 m Width: 44 mm At a glance Nominal input voltage 100-240 V AC input frequency 50 - 60 Hz Maximum current 20 A Load capacity 3680 VA Maximum input current per phase 16 A Maximum total current draw per phase 16 A Maximum power 3680 W PDU types Basic
All 32 specifications Specifications Power Nominal input voltage 100-240 V AC input frequency 50 - 60 Hz Maximum current 20 A Load capacity 3680 VA Maximum input current per phase 16 A Maximum total current draw per phase 16 A Maximum power 3680 W
Design PDU types Basic Type Single-phase Rack capacity 0U/1U Mounting Horizontal/Vertical Product colour Black
Certificates Compliance certificates RoHS Certification cUL Listed, CE, EAC, IRAM, PSE, UL Listed, VDE, REACH
Logistics data Total carbon footprint (kg of CO2e) 38.04
Packaging data Package weight 2.02 kg Package width 210 mm Package depth 76 mm Package height 436 mm
Ports & interfaces AC outlets quantity 13 AC outlet(s) Power plug C20 coupler AC outlet types C13 coupler Output connections IEC 320 C13
Weight & dimensions Width 44 mm Depth 93 mm Height 388 mm Weight 1.5 kg
Operational conditions Operating temperature (T-T) 0 - 50 °C Storage temperature (T-T) -15 - 60 °C Operating relative humidity (H-H) 5 - 95% Storage relative humidity (H-H) 5 - 95% Operating altitude 0 - 3048 m
$174.79 inc GST
