The Step-Down Transformer converts high voltage (208 or 200 VAC) output into low voltage (120 or 100 VAC) output for powering low voltage AC equipment.
Key features
Product colour: Black
Input connection type: Hard Wire 3-wire (2PH + G), Hard Wire 3 wire (1PH+N+G)
Output connections: 1x Hard Wire 3-wire (H N + G)
Nominal input voltage: 230 V
Nominal output voltage: 230 V
Load capacity: 10000 VA
Maximum input current per phase: 60 A
Maximum total current draw per phase: 60 A
Certification: C-tick,CE,CSA,EN 55022 Class A,EN 55024,EN 61000-3-2,EN 61000-3-3,GOST,UL Listed,VDE
Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -25 - 65 °C
Operating relative humidity (H-H): 0 - 95%
Storage relative humidity (H-H): 0 - 95%
Width: 432 mm
Depth: 749 mm
Height: 175 mm
Weight: 100 kg
Total carbon footprint (kg of CO2e): 10587.81
Specifications
Power
Nominal input voltage
230 V
Nominal output voltage
230 V
Load capacity
10000 VA
Maximum input current per phase
60 A
Maximum total current draw per phase
60 A
Design
Product colour
Black
Certificates
Certification
C-tick,CE,CSA,EN 55022 Class A,EN 55024,EN 61000-3-2,EN 61000-3-3,GOST,UL Listed,VDE
Logistics data
Total carbon footprint (kg of CO2e)
10587.81
Ports & interfaces
Input connection type
Hard Wire 3-wire (2PH + G), Hard Wire 3 wire (1PH+N+G)
