| USB | 1 x USB 10Gbps connector (supports USB Type-C), 1 x USB 5Gbps header supports 2 additional USB 5Gbps ports, 1 x USB 2.0 header supports 2 additional USB 2.0 ports |
|---|
| Miscellaneous | 3 x Addressable Gen 2 headers, 1 x Clear CMOS header, 1 x Chassis Intrusion header, 1 x Front panel audio header (F_AUDIO), 1 x 10-1 pin Front System Panel header, 1 x Thunderbolt (USB4) header |
|---|
| Power related | 1 x 24-pin Main Power connector, 2 x 8-pin +12V Power connectors |
|---|
| Storage related | 3 x M.2 slots (Key M), 4 x SATA 6Gb/s ports |
|---|
| Intel B860 Chipset | 1 x PCIe 4.0 x4 slot |
|---|
| Rear USB (Total 8 ports) | 1 x USB 20Gbps port (1 x USB Type-C), 2 x USB 10Gbps port (2 x Type-A), 4 x USB 5Gbps ports (4 x Type-A), 1 x USB 2.0 ports (1x Type-A) |
|---|
| Front USB (Total 5 ports) | 1 x USB 10Gbps connector (supports USB Type-C), 1 x USB 5Gbps header supports 2 additional USB 5Gbps ports, 1 x USB 2.0 headers support 2 additional USB 2.0 ports |
|---|
| Intel Core Ultra Processors(Series 2) | M.2_1 slot (Key M), type 2280 (supports PCIe 5.0 x4 mode) |
|---|
