ATEN 2 PORT 1U 10A SMART PDU WITH OUTLET CONTROL, 2XC13 OUTLETS

Networking > Network Accessories

  • Brand: ATEN
  • Category: Networking
  • SKU: PE4102G-AT-G
  • MPN: PE4102G-AT-G
ATEN

ATEN 2-Outlet Eco PDU Power Controller

SKU
CNZ-DD-040366
MPN
PE4102G-AT-G

Overview

Engineered to be an intelligent power distribution solution, the PE4102G Eco PDU Power Controller ships with 2 power outlets in an IEC socket configuration. It provides secure, centralized, intelligent, and remote power management of data center IT equipment to minimize operating costs.

The PE4102G features the remote power control function, allowing you to control devices attached to the PDU at the PDU device level from practically any location via a TCP/IP connection. The power sequence design eliminates the risks of power inrush, guaranteeing reliable operation and protecting the overall system health. With the support for eco DC software, it provides an easy method for managing multiple devices, offering an intuitive and user-friendly Graphical User Interface that allows you to configure a PDU device and reboot the device in case any equipment lock-up occurs. Additionally, the auto ping and auto reboot functions ensure devices remain responsive by automatically detecting connection issues and rebooting when necessary. Administrators can switch on/off or set a delay time for each power outlet or individual power outlet group whenever, wherever.

The PE4102G boasts a slim, compact form factor and supports desk mount, wall mount, as well as rack mount, ensuring easy installation in confined spaces. It is a smart eco PDU power controller tailored for hospitality or retail applications, such as digital signage and video walls, for edge computing devices, including routers, servers, and cameras, or for any data center environments where there is no need to keep the servers powered on at all times.

Key features

  • PDU types: Managed
  • Rack mounting: Yes
  • Mounting type: Desk/Wall
  • Product colour: Black
  • AC outlets quantity: 2 AC outlet(s)
  • Power plug: C14 coupler
  • AC outlet types: C13 coupler
  • Ethernet LAN (RJ-45) ports: 1
  • Cable length: 3 m
  • Password protection: Yes
  • Supported network protocols: TCP/IP, UDP, HTTP, HTTPS, SSL, SMTP, ARP, NTP, DNS, SNMP V1&V2&V3
  • Nominal input voltage: 100 - 240 V
  • AC input frequency: 50 - 60 Hz
  • Maximum current: 10 A
  • Nominal output voltage: 100 - 240 V
  • Load capacity: 2400 VA
  • Compliance certificates: Low Voltage Directive (LVD), CE, Electromagnetic Compatibility (EMC)
  • Operating temperature (T-T): 0 - 50 °C
  • Storage temperature (T-T): -20 - 60 °C
  • Operating relative humidity (H-H): 0 - 80%
  • Width: 127.8 mm
  • Depth: 170 mm
  • Height: 44 mm
  • Weight: 980 g

Specifications

Power

Nominal input voltage100 - 240 V
AC input frequency50 - 60 Hz
Maximum current10 A
Nominal output voltage100 - 240 V
Load capacity2400 VA

Design

PDU typesManaged
Rack mountingYes
Mounting typeDesk/Wall
Product colourBlack

Features

Cable length3 m
Password protectionYes

Certificates

Compliance certificatesLow Voltage Directive (LVD), CE, Electromagnetic Compatibility (EMC)

Logistics data

Country of originChina
Master (outer) case net weight4.9 kg
Master (outer) case width232 mm
Master (outer) case length500 mm
Master (outer) case height283 mm
Master (outer) case gross weight6.92 kg
Master (outer) case volume32819.225200128 cm³

Packaging data

Package weight1.27 kg
Package width95 mm
Package depth265 mm
Package height220 mm
Package volume5550.101932032 cm³

Packaging content

Cables includedAC
ManualYes

Ports & interfaces

AC outlets quantity2 AC outlet(s)
Power plugC14 coupler
AC outlet typesC13 coupler
Ethernet LAN (RJ-45) ports1

Management features

Supported network protocolsTCP/IP, UDP, HTTP, HTTPS, SSL, SMTP, ARP, NTP, DNS, SNMP V1&V2&V3

Weight & dimensions

Width127.8 mm
Depth170 mm
Height44 mm
Weight980 g

Operational conditions

Operating temperature (T-T)0 - 50 °C
Storage temperature (T-T)-20 - 60 °C
Operating relative humidity (H-H)0 - 80%

Questions

$441.59inc GST
