DYNAMIX 305m F/UTP CAT6 23 AWG, UV Stabilised with Jelly Filled
305m F/UTP CAT6 23 AWG UV Stabilised w/ Jelly Filled Cable
- Brand: Dynamix
- Category: Ethernet Cables
- SKU: C-STPC6SLD-GEL
- MPN: C-STPC6SLD-GEL
DynamixDYNAMIX 305m F/UTP CAT6 23 AWG, UV Stabilised with Jelly Filled
- SKU
- CNZ-CD-000883
- MPN
- C-STPC6SLD-GEL
Overview
DYNAMIX 305m F/UTP CAT6 23 AWG, UV Stabilised with Jelly Filled Cable
Specifications
Packing
| Packing | Wooden Tray & Carton |
|---|
Surface
| Surface | Clean, Frap, Satiation |
|---|
Material
| Material | Solid Bare Copper |
|---|
After Aging
| After Aging | Elongation (%): ≥300 |
|---|
Colour (13)
| Colour (13) | Surface Printing |
|---|
Core Colour
| Core Colour | 1 White-Blue/Blue2 White-Orange/Orange3 White-Green/Green4 White-Brown/Brown |
|---|
Before Aging
| Before Aging | Tensile Strength (Mpa): ≥10.0Elongation (%): ≥350 |
|---|
External O.D.
| External O.D. | 7.8 ± 0.4 mm |
|---|
Material (11)
| Material (11) | LDPE (complies RoHS) |
|---|
Nom. O.D.(mm)
| Nom. O.D.(mm) | 0.565Up: +0.005Down: -0.005 |
|---|
Rip-cord (21)
| Rip-cord (21) | Sheath Physical Properties |
|---|
Nom. O.D.(mm) (3)
| Nom. O.D.(mm) (3) | Insulation |
|---|
Screening Material
| Screening Material | Mylar +Al/Mylar |
|---|
Print Error & Space
| Print Error & Space | ≤±0.5%, 1m |
|---|
Screening Material (7)
| Screening Material (7) | Sheath |
|---|
Aging Period (°C x hrs)
| Aging Period (°C x hrs) | 100°C x 24h x 10days |
|---|
Cold bend (-20±2 °Cx4h)
| Cold bend (-20±2 °Cx4h) | 8×Cable O.D., No visible cracks |
|---|
Velocity of Propagation (%)
| Velocity of Propagation (%) | 68 |
|---|
DC Resistance (Ω/100m) max.
| DC Resistance (Ω/100m) max. | 9.38 |
|---|
Cold bend (-20±2 °Cx4h) (26)
| Cold bend (-20±2 °Cx4h) (26) | Electrical Characteristics (20°C) |
|---|
Unbalanced-to-ground capacitance
| Unbalanced-to-ground capacitance | 330 (pf/100m) max |
|---|
DC Conductor Resistance Unbalance (%) max.
| DC Conductor Resistance Unbalance (%) max. | 5.0 |
|---|
$780.84inc GST
