up to 93.5% in online mode (up to 98% in Hi-efficiency mode)
Format (2)
Format (2)
Electrical characteristics
Technology
Technology
On-line double conversion with Power Factor Correction (PFC) system
Rating (VA/W)
Rating (VA/W)
2200VA/2200W
Efficiency (8)
Efficiency (8)
Connections
Nominal voltage
Nominal voltage
200/208/220/230/240V
Battery management
Battery management
ABM® & temperature compensated charging method (user selectable), automatic battery test, deep discharge protection, automatic recognition of external battery units
Communication slot
Communication slot
1x slot for Network-MS card (included in netpack versions), ModBus-MS or Relay-MS cards
Communication ports
Communication ports
1x USB port + 1x serial RS232 port + 1x mini-terminal block for remote ON/OFF + 1x mini-terminal block for remote power off + 1x mini-terminal block for output relay
Input voltage range
Input voltage range
176V~276V without derating (up to 100V~276V with derating)
Typical noise level
Typical noise level
40dB
Approvals & markings
Approvals & markings
CE /CB report (TUV) / cULus / EAC /RCM / KC / Energy Star
Input frequency range
Input frequency range
40~70Hz, 50/60Hz auto selection, frequency converter mode
Operating temeprature
Operating temeprature
0°C~40°C
Switched outlet group
Switched outlet group
2 outlet groups
Typical backup times*
Typical backup times*
800W
Battery management (16)
Battery management (16)
Communication
Communication slot (19)
Communication slot (19)
Operating conditions, standards and approvals
Approvals & markings (25)
Approvals & markings (25)
Dimensions H x W x D in mm/ Weight
Outputs on HotSwap models
Outputs on HotSwap models
4x FR/Schuko sockets or 3x BS sockets or 6x IEC 10A sockets or terminal blocks (HW version)
