The fastest, most secure network scanner helps accelerate your business forward.[1,2] The fastest, most secure network scanner helps accelerate your business forward. Utilising high-performance features for a more productive office.[1,2]
Auto document feeder (ADF) input capacity: 150 sheets
USB port: Yes
Ethernet LAN: Yes
Security algorithms: SNMPv3, TLS, FIPS 140, HTTPS, IPSec
Power supply type: AC
Power consumption (typical): 22 W
Power consumption (off): 0.3 W
Power consumption (PowerSave): 1.2 W
AC input frequency: 50/60 Hz
Power consumption (sleep): 1.2 W
Specifications
Power
Power supply type
AC
Power consumption (typical)
22 W
Power consumption (off)
0.3 W
Power consumption (PowerSave)
1.2 W
AC input frequency
50/60 Hz
Power consumption (sleep)
1.2 W
Design
Scanner type
Flatbed scanner
Display
LCD
Control type
Touch
Built-in display
Yes
Network
Ethernet LAN
Yes
Security algorithms
SNMPv3, TLS, FIPS 140, HTTPS, IPSec
Scanning
Colour scanning
Yes
Duplex scanning
Yes
Greyscale levels
256
Performance
Scan file formats
CSV, HTML, JPG, OCR, PDF, RTF, TIFF, TXT, XPS
Maximum duty cycle
10000 pages per month
Scan to
E-mail, Network folder, USB, FTP
Scan drivers
ISIS, TWAIN, WIA
Internal memory
3584 MB
Processor frequency
1200 MHz
HP segment
Business
Certificates
Electromagnetic compatibility
CISPR 22:2008 (International) - Class A, CISPR 32:2012 (International) - Class A, EN 55032: 2012 (EU) - Class A, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 55024: 2010, EMC Directive 2014/30/EU, FCC CFR 47 Part 15 Class A / ICES-003, Issue 6 Class A. Other EMC approvals as required by individual countries
Input capacity
Auto document feeder (ADF) input capacity
150 sheets
Logistics data
Pallet dimensions (W x D x H)
1200 x 1000 x 2194 mm
Products per pallet
15 pc(s)
Country of origin
China, Mexico
Layers per pallet
3 pc(s)
Pallet dimensions (W x D x H) (imperial)
1199.9 x 1000 x 2193.8 mm (47.2 x 39.4 x 86.4")
Pallet weight (imperial)
305.2 kg (672.9 lbs)
Pallet gross weight
305.2 kg
Master (outer) cases per pallet layer
5 pc(s)
Harmonized System (HS) code
84716070
Other features
Network ready
Yes
Cable lock slot
Yes
Recommended system requirements
2 GB available hard disk space; Internet; For HP Scan; Windows 11; 10; 8.1; 8; 7; XP; 32-bit or 64-bit; 2 GB available hard disk space; CD-ROM/DVD drive or Internet connection; USB port; Internet Explorer; 2 GHz processor; 2 GB RAM; 1024 x 768 SVGA monitor.
1.3 GB available hard drive space; Internet.
Dimensions (WxDxH)
512 x 585.3 x 263.4 mm
Recommended operating temperature range (T-T)
10 - 35 °C
Control panel
XGA 1024x768 LCD
Media types supported
ADF: Paper (Plain, Inkjet, Inkjet Brochure/Glossy), Photo Paper; Flatbed: All ADF Media, Envelopes, Labels, Cards, Books
Image formats supported
BMP, JPEG, MTIFF, PNG, TIF, TIFF
UNSPSC-code
43211711
Recommended media weight
45 - 199 g/m²
Box contents
HP Digital Sender Flow 8500 fn2 Document Capture; Hardware install guide; HP 8500 fn2 HbrCD for Mac And PC; HP user's guide regulatory Info CD; Power cord; USB cable
Interface
USB, 10/100/1000 Ethernet
Certification
CISPR 22:2008 (International) - Class A, CISPR 32:2012 (International) - Class A, EN 55032: 2012 (EU) - Class A, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 55024: 2010, EMC Directive 2014/30/EU, FCC CFR 47 Part 15 Class A / ICES-003, Issue 6 Class A. Other EMC approvals as required by individual countries
Packaging data
Package dimensions (WxDxH)
599 x 396 x 731 mm
Package width
599 mm
Package depth
396 mm
Package height
731 mm
Package weight
20.3 kg
Sustainability
Sustainability compliance
Yes
Sustainability certificates
ENERGY STAR, EPEAT
Total carbon footprint (kg of CO2e)
600
Packaging content
Cables included
USB, AC
Bundled software
HP browser, Mac OS Welcome Screen (Directs users to HP.com or OS App Source for printer software), Online user manuals. Download from hp.com Network TWAIN (32-bit and 64-bit), and USB TWAIN (32-bit and 64-bit) solution, WIA, Kofax VRS Pro
Technical details
Scan technology
CIS/CCD
Ports & interfaces
USB port
Yes
System requirements
Minimum system requirements
2 GB available hard disk space; OS hardware requirements see microsoft.com or 1.3 GB available hard drive space; Internet; For HP Scan: Windows 11, 10, 8.1, 8, 7, XP: 32-bit or 64-bit, 2 GB available hard disk space, CD-ROM/DVD drive or Internet connection, USB port, Internet Explorer, 2 GHz processor, 2 GB RAM, 1024 x 768 SVGA monitor
Compatible operating systems
Windows 11; Windows 10; Windows 8; Windows 8.1; Windows 7; macOS X 10.10 Yosemite; macOS 10.11 El Capitan; macOS 10.12 Sierra; Linux; UNIX
Windows operating systems supported
Windows 7, Windows 8, Windows 8.1, Windows 10, Windows 11
Mac operating systems supported
Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, MacOS
