IDS-409G3-C2SD10-SD120 Industrial Managed Switch 9 ports: 6 x 10/100/1000Base-T Base-T RJ-45 ports and 2 x 1000Base-LX/LH 1310nm single mode port with duplex SC connector [10 km/ 6.2 miles ] and 1 x
IDS-409G3-C2SD10-SD120 Industrial Managed Switch 9 ports: 6 x 10/100/1000Base-T Base-T RJ-45 ports and 2 x 1000Base-LX/LH 1310nm single mode port with duplex SC connector [10 km/ 6.2 miles ] and 1 x
Specifications
Brand
Brand
Perle
Ports
Ports
Ethernet
Vendor
Vendor
Perle
Weight
Weight
640 g
Ethernet
Ethernet
Ethernet
Features
Features
Fanless
Material
Material
Compact
Warranty
Warranty
5 years
Managable
Managable
Ethernet
Media type
Media type
Ethernet
Form factor
Form factor
Compact
Vendor code
Vendor code
Perle
Vendor site
Vendor site
Perle
Power source
Power source
12 V DC, 24 V AC, 24 V DC, 48 V DC, 60 V DC, 9.6 V DC
Product name
Product name
Perle
Product type
Product type
Perle
Display depth
Display depth
74.9 mm
Display width
Display width
74.9 mm
Input voltage
Input voltage
12 V DC, 24 V AC, 24 V DC, 48 V DC, 60 V DC, 9.6 V DC
Network layer
Network layer
Ethernet
Product model
Product model
Perle
What's in box
What's in box
IDS-409G Managed Industrial Ethernet Switch with Gigabit Fiber 9 port Compact DIN Rail Switch Terminal block Installation guide DIN Rail attachment
Display height
Display height
74.9 mm
Ethernet ports
Ethernet ports
Ethernet
Product family
Product family
Perle
Product series
Product series
Perle
Network technology
Network technology
Ethernet
Ethernet technology
Ethernet technology
Ethernet
Compliance & standards
Compliance & standards
Safety UL/EN/IEC 62368-1 CAN/CSA C22.2 No. 62368-1 UL 60950-1 IEC 60950-1(ed 2) am1, am2 EN 60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013 UL 61010-1 and UL 61010-2-201 (Standard for Safety for Programmable Controllers) Formerly known as UL508 UL/IEC 61010-1 UL/IEC 61010-2 CE Mark Emissions FCC 47 Part 15 Class A CISPR 32:2015/EN 55032:2015 (Class A) EMC and Immunity CISPR 24:2010/EN 55024:2010 IEC/EN 61000-4-2 (ESD) : Contact discharge +/- 4kv, Air discharge +/- 8kv IEC/EN 61000-4-3 (RS) : 80mhz to 1Ghz 20v/m, 1.5hkz to 2.0ghz 10 v/m, 2.0ghz to 2.7 ghz 5 v/m IEC/EN 61000-4-4 (EFT) : DC power line +/- 2kv, data line +/- 1kv IEC/EN 61000-4-5 (Surge) : DC power line, Line/Line +/- 1kv, Line/Earth +/- 2kv, data line /earth +/- 2kv IEC/EN 61000-4-6 (CS) :150mhz-80mhz 10vrms IEC/EN 61000-4-8 (Magnetic Field) :30 A/M IEC/EN 61000-6-2 (General Immunity in Industrial Environments) Hazardous Locations (Hazloc) ANSI/ISA 12.12.01, Class 1 Division 2 Groups A-D (formerly known as UL 1604) ATEX Class 1 Zone 2 EN 60079-0:2012+A11:2013 and EN 60079-15:2010 Other ECCN: 5A991 HTSUS Number: 8517.62.0020
